High-Performance Drift Separator Installations

Blade drift separators are highly effective drift separators and can be adapted to the relevant installation conditions. Thanks to the very robust profile traps, they can also be cleaned of coarse dirt using a high-pressure cleaner, which extends the operating life of the system.

Blade drift separators have a special additive that provides effective UV protection. This also guarantees a long service life with sustainable long-term efficiency with only a very small drop in pressure.

Special attention is paid to environmental compatibility (solvent-free), simple and quick mechanical processing by means of patented assembly technology. Furthermore, every local fire protection requirement is strictly observed.

Key Features

High durability: Use of ageing-resistant, effective materials

Compliant with the highest fire protection regulations: Own formula using highly effective additives

Modular assembly using spacers: Profiles remain in a fixed position after assembly

High sedimentation rate: Thanks to specially designed structure

Features

Standard dimensions: 6000 x 188 (Length x Height) Other sizes available on request

Sedimentation rate: < 0.005%

Material: Polypropylene (PP); Polyvinylchloride (PVC)

Operating temperatures: 75° C - fixed - , max. 80° C - short-term

Flammability rating: DIN 4102-B2
